Details
Technische Daten
| Akkuleistung in Wh | 800 Wh |
| Akku | Bosch PowerTube, 800Wh |
| Beleuchtung | ja |
| Bremse | Tektro M535 4-piston hydraulic disc, 203mm rotors |
| Bremshebel | Tektro M535 hydraulic disc |
| Dämpfer | SR Suntour Edge Evo R, Air, adjustable rebound, 230x52.5mm |
| Display | Bosch Purion 200 |
| Erhältliche Rahmenhöhen | S, M, L, XL |
| Federweg dämpfer mm | 130 mm |
| Federweg gabel mm | 150 mm |
| Felgen | WTB ST i30 TCS, 30mm inner width, 32h, tubeless ready |
| Gabel | SR Suntour Zeron 36-X Boost, 150mmm, EQ Air, compression & rebound adjust, 15x110mm thru-axle, tapered steerer, 44mm offset |
| Gepäckträger | ja |
| Griffe | Cannondale TaperRidge |
| Highlight | nein |
| Jahr | 2025 |
| Kassette/Zahnkranz | Shimano CUES LG400, LinkGlide, 11-50, 11-speed |
| Kette | Shimano LG500, LinkGlide, 11-speed |
| Kurbel | FSA Bosch E-bike w/ 55mm chainline, 160mm, 34T |
| Ladegerät | Bosch 4A |
| Laufradgröße | 29'' |
| Lenker | Cannondale 3 riser, 6061 Alloy, 25mm rise, 8° sweep, 4° rise, 800mm |
| Motor | Bosch Performance Line CX |
| Naben | (F) Shimano TC500, 15x110mm thru-axle / (R) Shimano TC500, 12x148mm thru-axle, centerlock |
| Pedale | Nicht im Lieferumfang enthalten |
| Pedelec Antrieb | Mittelmotor |
| Rahmen | Moterra, SmartForm C1 Alloy, 29" wheels, 130mm travel, Proportional Response Tuned Suspension, removable downtube battery, alloy skid plate, 55mm chainline, internal cable routing, 148x12mm thru-axle, UDH, 200mm native post mount brake, 1.5” – 1.8” tapere |
| Rahmenform | Diamant |
| Rahmenmaterial | Aluminium |
| Reifen | Schwalbe Johnny Watts Performance, Black Reflex, 29x2.35", ADDIX compound, tubeless ready |
| Sattel | WTB Silverado Medium |
| Sattelstütze | Cannondale DownLow Dropper, internal routing, 34.9, 150mm (S), 170mm (M), 200mm (L), 230mm (XL) |
| Schalthebel | Shimano CUES U6000, 11-speed, LinkGlide |
| Schaltung | Kettenschaltung |
| Schaltwerk | Shimano CUES U6000, LinkGlide |
| Schutzbleche | ja |
| Speichen | DT Swiss Champion 2.0 |
| Steuersatz | Acros ICR, 1.5" to 1.8", sealed bearings |
| Vorbau | Cannondale 1, 6061 Alloy, 35.0, 40mm, 0° |
