Details
Technische Daten
Akkuleistung in Wh | 504 Wh |
Akku | 504 Wh |
Beleuchtung | ja |
Bremse | Shimano BR-MT200, 2-piston, hydr. disc brake |
Display | integrated in display |
Gabel | SR Suntour XCM32-ATB, coil, 80 mm, tapered |
Gepäckträger | Raymon, MIK, 25 kg |
Griffe | Raymon Ergo, lock on |
Jahr | 2025 |
Kassette/Zahnkranz | Shimano SM-GEAR, 19T |
Kette | KMC Z1eHX |
Ladegerät | Charger, 4 A |
Laufradgröße | 27,5'' |
Laufradsatz | Raymon VR18/Shimano QC300/C6001-8D |
Motor | Yamaha PW-C2, 250/500 W, 55 Nm |
Pedale | Standard |
Pedelec Antrieb | Mittelmotor |
Rahmen | 27.5", Alloy 6061, removeable battery |
Rahmenmaterial | Aluminium |
Reifen | Continental eContact Plus, Reflex, 55-584, 27.5x2.20 |
Schalthebel | Shimano Nexus, SL-C6000, Revoshift |
Schaltung | Nabenschaltung |
Schaltwerk | Shimano Nexus, SG-C6001, 8-S |
Scheinwerfer | AXA Nxt 30, 30 lx |
Schutzbleche | SKS PET |
Ständer | Raymon, KSA18, adjustable |
Vorbau | Raymon 31.8, Ahead, adjustable |
Zulässiges Gesamtgewicht in kg | 130 kg |
